TP-Link AC1200 WiFi Bluetooth 4.2 PCIe Adapter Archer T5E

Model

Archer T5E - AC1200 WiFi Bluetooth 4.2 PCIe Adapter

Part No

ARCHER T5E(UN)

Color

Black

Interface

PCI Express

Antenna

2 Detachable External Antennas

Standards and Protocols

Bluetooth 4.2, Bluetooth 4.0

Interface

USB 2.0

Wireless Standards

IEEE 802.11b/g/n 2.4 GHz, IEEE 802.11a/n/ac 5 GHz

Signal Rate

11ac: Up to 867 Mbps(dynamic)

11n: Up to 300 Mbps(dynamic)

11a: Up to 54 Mbps(dynamic)

2.4 GHz:

11n: Up to 300 Mbps(dynamic)

11g: Up to 54 Mbps(dynamic)

11b: Up to 11 Mbps(dynamic)

Reception Sensitivity

5 GHz:

11ac HT80: -59.0dBm

11n HT40: -68.5dBm

11a 54Mbps: -73.5dBm

11a 6Mbps: -91dBm

2.4 GHz:

11n HT40: -69.5dBm

11g 54Mbps: -74dBm

11b 11Mbps: -87dBm

Transmit Power

21.5dBm(FCC)

2.4 GHz : 20.5dBm(FCC)

Wireless Modes

Infrastructure mode

Wireless Security

WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Modulation Technology

DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

System Requirements

Windows 11/10/8.1/8/7 (32/64 bit)

Operating Temperature

0℃~40℃ (32℉ ~104℉)

Storage Temperature

-40℃~70℃ (-40℉ ~158℉)

Operating Humidity

10%~90% non-condensing

Storage Humidity

5%~90% non-condensing

Package Content

AC1200 WiFi Bluetooth 4.2 PCIe Adapter Archer T5E

Low-Profile and Full Height Brackets

Quick Installation Guide

Bluetooth USB Cable

Resource CD

Dimensions

4.8 × 3.3 × 0.85 in (120.8 × 83.2 × 21.5 mm)

Weight

0.23 Kg

Warranty

1 Year ( As per Manufacturer Policy )
